Ortur Laser Master 2 Pro available

by on29 September 2021


Sponsored article: Higher speed and precision


Apple made a big success with engraving iPads a few years back, and the engraving was always a desirable and high-quality branding method but usually cost a bit too much.

With the introduction of Ortur Laser Master 2 Pro, engraving for small businesses comes at a very affordable price. Yet, the device is easy to use and produces excellent speed and quality.

The device evolves around four key pillars. It offers more precision for its class, faster operation, reliability, and more safety than the competition.

The first thing that might be on everyone's mind is what kind of materials the device supports. The answer is plenty, and it includes, Aluminum spray paint ② Anodized Aluminum ③ Black Acrylic ④ Bread ⑤ Color Paper ⑥ International chess ⑦ Leatherette ⑧ Mobile phone plastic shell ⑨ Mood ⑩ Mirror and Sprayed Title.


OrthuroPic

Optimized focal spots

The brain of the operation is the Advanced Control Board branded OLM-PRO-V10, and it is the 3rd generation motherboard, with 32-bit MCU +24V Circuit. The Beta version of the board is named OLM-MAXUP-V10.

The board enables better precision, and it has optimized 0.08mm*0.15mm focal spot and can easily penetrate 9mm plywood. The result is a more realistic and natural grayscale gradient capable of superb reproduction of your ideas.

The Advanced Laser Module uses an Advanced high power 2nd generation FAC technology laser module and supports multiple power options ranging between 1W to 40W. It supports smaller Light Spots starting from a tiny 0.08mm*0.15mm focal spot. The number represents a quarter of the other competing lasers that traditionally operate with 0.23mm*0.23mm spots.

High Precision Power Control ensures that the laser power can be controlled with an accuracy of one-thousandth, carving richer details. Due to the use of a 12bit precision PWM control signal, more than 1000 grayscale performances provide authentic photo-like details.

A 50mm fixed-focus thinner laser beam can cut a thicker object at the same amount of power. The depth can penetrate objects as thick as 9 mm.

Faster Speed

The engraving speed of Laser Master 2 pro is twice that of Laser Master 2, three times more than most of the competition with up to 10,000mm/min engraving speed.

The latest Ortur Laser 1.5 firmware is more powerful. The Ortur engineer team optimized the motion algorithm based on the previous series' firmware, increasing the maximum speed from 4000mm/min to 10,000mm/min.

It supports a High-Speed USB CDC Interface. Compared with the traditional USB to serial port supporting a 921,600 baud rate, the MCU native USB CDC interface supports a baud rate as high as 2,000,000. It dramatically reduces the delay caused by command transmission, shortening the engraving time.

Fast Engraving Speed is achieved by a specially optimized motion algorithm combined with a strong machine frame, light motion components, and a high-power laser module. Ortur Laser Master 2 Pro has lightweight Moving Parts. The driving motor of the X-axis, designed to move the laser module, was placed to the right of the Y-axis. It greatly reduces the load of X-axis movement. The High-Precision Motion enables Higher precision control, more perfect engraving details.

More Reliable

Some of the vital advantage points include modular, all-metal construction, convenient assembly, high precision parts combination, and longer service life. The towline-covered cable can withstand more than 5,000,000 bends. The devices support 24 hours uninterrupted operation.

It supports a 24V Electric System. The OLM-PRO-V10 Motherboard has a safer 24V high-efficiency electric system, reduces the current by half compared to 12V at the same power. The device could support the powerful laser module up to 60W, as well as more add-ons.

The laser module comes with a laser protection shield made of the same material as laser protection glasses. It can shield the high-brightness laser source and high-frequency flashing laser to protect users' eyes from laser-related injuries. A scale is printed on the aluminum profile for EAS of position adjustment. High-quality flexible cable can withstand high and low temperature, aging resistance, repeated folding times. Cables Chains are in place to protect moving wires, enabling an attractive and clean design.

Safety features

The Ortur Laser Master 2 Pro can provide users with better security because it includes more security features. One of them is Active Position Protection. When the machine is displaced or tilted, it will automatically stop the laser to prevent damage caused by the laser shot out of the target.

Laser Beam Safety Guard is also in place. It will automatically stop the laser in case of the computer crashing during the engraving process. Exposure Duration Detection and Limitation ensures that it can stop the laser when the motor doesn't move for a while.  One of the safety features includes the flame detector and buzzer alarm. In case the flame is detected, the buzzer alarm would sound and light alarm.

As this is a class 2 laser device, it comes with an Emergency Stop Button. In case of emergency, a single press of the button will stop the operation immediately.

Pricing

The Ortur Master 2 Pro is available in multiple countries across Europe in US, EU, and China warehouses. The pricing ranges between $459 and approximately € 449.99.

Engraving a musical instrument, a gift box, phone, or a laptop comes at a very affordable range and can easily create a quick return on investment. Customers simply like customization and unique way to engrave their device, as long as the retailer picks a price that customers are willing to invest.

You can get them in Netherlands/Spain/Czech/Italy/UK/Estonia from Ortur.net for $459 with the Code Orturpro ($10 less), ready to ship from the US, EU, or China warehouse. Alternatively, there are two other shops from Aliexpress here and here, both shipping out of China.

The Ortur Laser Master 2 Pro is also available in Poland from Ortur.net for $459 with the Code Orturpro ($10 less), ready to ship from the US, EU, or China warehouse. Alternatively, there are also available from Aliexpress and allegro.pl (1799PLN ($463.59) shipping out of China.

Customers from Germany can get the Ortur Laser Master 2 Pro from Ortur.net for $459 with the Code Orturpro ($10 less), ready to ship from the US, EU, or China warehouse. Alternatively, there are also available from Kaufland.de for € 449.99 shipping out of the EU.

Customers from Germany can get the Ortur Laser Master 2 Pro from Ortur.net for $459 with the Code Orturpro ($10 less), ready to ship from the US, EU, or China warehouse. Alternatively, there are also available from Aliexpress for $449 shipping out of China.

US and Canadian customers can order the Ortur Laser Master 2 Pro from Ortur.net for $459 with the Code Orturpro ($10 less), ready to ship from the US, EU, or China warehouse. Alternatively, there are also available from Aliexpress for $449 shipping out of China.
